Select package code by brand positioning; record in contract appendix and stocking list.
- E1–X1Five-tier package
Brand selection grid - v2.xBOM version
In contract - BatchUnified firmware
Cross-property spares - checklistNew property acceptance
Points/scenes
Five-tier package · typical categories
Tier sets circuit scale and panel grade — models per signed BOM v2.x.
Tender citation · three-step method
Chain tender should bind BOM version and acceptance checklist to avoid ad-hoc changes at new properties.
Firmware, register table, panel silkscreen ship with v2.x — no on-site model swaps.
Points, scenes, address table copied after mock-up acceptance.
* Five tiers are tender quick view; full circuit list seeChain copy plan。
Five-tier package overview · E1–X1
Click tier for circuit scale and typical combo — appendix may cite tier code; models per signed BOM version.
Typical combo:Card power + door lock + basic wireless panels · 8-circuit wireless gateway · no dimming.
Network:Wireless RCU· suited to express / economy chain.
Typical combo:Card power + DND/MUR door sign + scene panel ×2· wired / RS485 optional.
Network:Wired/RS485· aligned to six-point standard room BOM.
Typical combo:LCD scene + dimming + FCU module · RS485 open protocol · Welcome preset.
Network: RS485 bus · chain primary tier, spares cross-property.
Typical combo:Comfort panel matrix + public-area linkage + dual curtain channels · 24-circuit host.
Network: wired / modular · seeLuxury reference。
Typical combo:Luxury OEM finish + multi-zone panels + banquet / multi-property custom BOM.
Network:Modular enclosure· drawings per project.
Contract must-haves · three items
Tender summary locks version and acceptance criteria — detail BOM on chain solution page.
| Tender fields | Example / notes | Responsible party |
|---|---|---|
| BOM version | HC-CHAIN-BOM-v2.3 (in contract appendix) | PurePoint Smart supply list |
| Tier code | E1 / S1 / C1 / P1 / X1 + property-type mapping table | Group engineering |
| Acceptance checklist | DI points / scene keys / terminal drawing version aligned | Integrator on site |
| Firmware channel | Zone batch push · fault property can freeze version | PurePoint Smart + integrator NOC |
