Hotel smart modules
Mesh wireless relay module
Relay, DI/DO and expansion modules for RS485 and wireless guestroom buses.
Mesh wireless relay module
Mesh wireless relay module — Mesh wireless relay for low-wiring retrofit projects. Mesh wireless relay module for mesh coverage extension; wireless actuator node for public and guest areas.
- Mesh wireless relay
- Mesh coverage
- Wireless actuator
- Public and guest areas
Mesh Wireless relay actuator module
RS485 bus Modbus RTU · with RCU networking
Installation DIN rail / low-voltage cabinet
Load confirm model selection per project
Application hotel guestroom · building public areas · centralized control
- Product
- Wireless relay module
- Series
- Wireless
- Features
- Mesh · relay · wireless
- Interfaces
- RS485 bus · Modbus RTU (model-dependent)
Specifications
| Parameter | Specification |
|---|---|
| Product name | Wireless relay module |
| Product series | relay / IO module |
| Key features | Mesh · relay · wireless · multi-circuit relay output · RS485 bus · DIN rail installation |
| Product overview | Wireless relay module — Mesh wireless relay for low-wiring retrofit projects. RS485 bus actuator, DIN-rail mount, pairs with hotel RCU host. |
| Installation | 86 mm back box / standard wall / LV cabinet (model-dependent) |
| Communication method | RS485 bus · Modbus RTU (model-dependent) |
| Delivery | Bulk project supply · finish and load per BOM |
| Applications | Hotel guestroom · building public areas · bulk projects |
| Engineering sup port | Detailed design docs · project BOM · bulk supply coordination |
Wiring diagram
Relay module engineering wiring reference — RS485 bus, mains output terminals and load matching. Per signed drawing set.
Installation notes
- module address must be at detailed design phase with RCU circuit schedule, scene schedule planned together
- DIN rail/low-voltage cabinet installation must reserved cooling space, terminals torque per factory specification
- Wire per project drawing; signed projects use factory shipment drawings
- after power-on with RCU commissioning: output actions, bus communication, scene linkage item-by-item acceptance
Downloads
Full datasheets, wiring diagrams and certificates are in the download center, or contact sales for project BOM.
Recommended for you
requires wireless relay actuation module selection and load matching？ Contact the team for load type confirmation, circuit schedule and module address planning.
